| Load Voltage | 24 to 280 VRMS |
| Type of Product | Solid State Relay |
| Height | 58.4 mm |
| Depth | 19.8 mm |
Load Voltage |
24 to 280 VRMS |
Type of Product |
Solid State Relay |
Height |
58.4 mm |
Depth |
19.8 mm |
Operating Temperature Range |
-40 to +80°C |
Mounting Type |
Panel Mount |
Series |
Series 1 240 VAC |
Maximum Load Current |
25 A |
Country of Origin |
Mexico |
Capacitance |
8 pF |
Length |
45.7 mm |
Leakage Current |
10 mA RMS |
Maximum Operating Temperature |
+80°C |
Contact Configuration |
SPST |
Terminal Type |
Screw |
Minimum Operating Temperature |
-40°C |
Dimension |
45.7x19.8x58.4 mm |
Relay Type |
Solid State Relay |
Output Device |
SCR |
Switch Type |
Instantaneous |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
280 V AC |
Minimum Load Current |
40mA RMS |
Minimum Control Voltage |
90 V AC |
Maximum Turn On Time |
10 ms |
Control Voltage Range |
90 to 280 V AC |
Maximum Load Voltage |
280 V RMS |
Minimum Load Voltage |
24 V RMS |
Product Code |
7360817 |
Pack of |
1 Pc |
Manufacturer Part Number |
A2425-10 |
Standards Met |
CE, CSA, RoHS Compliant |
