| Load Voltage | 1 to 60 V DC |
| Type of Product | Solid State Interface Relay |
| Height | 61 mm |
| Depth | 10 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
1 to 60 V DC |
Type of Product |
Solid State Interface Relay |
Height |
61 mm |
Depth |
10 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
DIN Rail |
Series |
DRA1 CMX |
Maximum Load Current |
5 A |
Country of Origin |
Mexico |
Capacitance |
15 pF |
Special Features |
Cage Style Screw Terminals For Easy And Reliable Wire Connection,Fits Standard 35mm DIN-RAIL |
Length |
89.6 mm |
Leakage Current |
100 μA |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-30°C |
Dimension |
89.6x10x61 mm |
Output Device |
AC; DC |
Switch Type |
DC |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
28 V DC |
Minimum Load Current |
0 A |
Minimum Control Voltage |
20 V DC |
Maximum Turn On Time |
1 ms |
Control Voltage Range |
20 to 28 V DC |
Maximum Load Voltage |
60 V DC |
Minimum Load Voltage |
1 V DC |
Product Code |
7018506 |
Pack of |
1 Pc |
Manufacturer Part Number |
DRA1-CMXE60D5 |
