| Load Voltage | 12 to 280 V AC |
| Type of Product | Solid State Interface Relay |
| No. of Pole | 1 |
| Height | 61 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
12 to 280 V AC |
Type of Product |
Solid State Interface Relay |
No. of Pole |
1 |
Height |
61 mm |
Width |
10 mm |
Depth |
10 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
DIN Rail |
Series |
DRA Series |
Maximum Load Current |
5 A RMS |
Country of Origin |
Mexico |
Capacitance |
10 pF |
Special Features |
Fits standard 35mm DIN rail, Includes LED Status indicator |
Length |
89.6 mm |
Leakage Current |
0.1 mA |
Maximum Operating Temperature |
+80°C |
Contact Configuration |
SPST |
Terminal Type |
Screw |
Minimum Operating Temperature |
-30°C |
Dimension |
89.6x10x61 mm |
Switch Type |
Instantaneous |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
0.06 A |
Minimum Control Voltage |
15 V DC |
Maximum Turn On Time |
1/2 cycle |
Control Voltage Range |
15 to 32 V DC |
Maximum Load Voltage |
280 V AC |
Minimum Load Voltage |
12 V AC |
Product Code |
7018544 |
Pack of |
1 Pc |
Manufacturer Part Number |
DRA1-CXE240D5R |
Standards Met |
CE, CSA, cURus |
