| Load Voltage | 48 to 530 V AC |
| Type of Product | Solid State Relay |
| Height | 30 mm |
| Depth | 73.4 mm |
Load Voltage |
48 to 530 V AC |
Type of Product |
Solid State Relay |
Height |
30 mm |
Depth |
73.4 mm |
Operating Temperature Range |
-40 to +80°C |
Mounting Type |
Panel Mount |
Series |
53TP |
Maximum Load Current |
50 A RMS |
Country of Origin |
Mexico |
Capacitance |
8 pF |
Length |
103.8 mm |
Leakage Current |
10 mA |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-40°C |
Dimension |
103.8x73.4x30 mm |
Output Device |
SCR |
Switch Type |
Zero Cross |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
280 V RMS |
Minimum Load Current |
0.05 A |
Minimum Control Voltage |
90 V RMS |
Maximum Turn On Time |
50 ms |
Control Voltage Range |
90 to 280 V AC |
Maximum Load Voltage |
530 V RMS |
Minimum Load Voltage |
48 V AC |
Product Code |
2181921 |
Pack of |
1 Pc |
Manufacturer Part Number |
A53TP50D |
Standards Met |
CE, CSA, RoHS Compliant |
