| Load Voltage | 12 to 280 V AC |
| Type of Product | Solid State Relay |
| Height | 34.3 mm |
| Depth | 22.8 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
12 to 280 V AC |
Type of Product |
Solid State Relay |
Height |
34.3 mm |
Depth |
22.8 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
PCB Mount |
Series |
PF |
Maximum Load Current |
25 A RMS |
Country of Origin |
Mexico |
Capacitance |
8 pF |
Length |
43.1 mm |
Leakage Current |
0.1 mA |
Maximum Operating Temperature |
+80°C |
Minimum Operating Temperature |
-30°C |
Dimension |
43.1x22.8x34.3 mm |
Output Device |
SCR |
Switch Type |
Zero Cross |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
15 V |
Minimum Load Current |
0.06 A |
Minimum Control Voltage |
3 V |
Maximum Turn On Time |
1/2 cycle |
Control Voltage Range |
3 to 15 V DC |
Maximum Load Voltage |
280 V RMS |
Minimum Load Voltage |
12 V RMS |
Product Code |
394462 |
Pack of |
1 Pc |
Manufacturer Part Number |
PF240D25 |
Standards Met |
CE, RoHS Compliant |
