| Load Voltage | 3 to 100 V DC |
| Type of Product | Solid State Relay |
| Height | 14.3 mm |
| Depth | 21.1 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
3 to 100 V DC |
Type of Product |
Solid State Relay |
Height |
14.3 mm |
Depth |
21.1 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
Panel Mount |
Series |
EL |
Maximum Load Current |
10 A |
Country of Origin |
Mexico |
Special Features |
Plastic Housing with min. 250 CTI Rating (PLC2) for Demanding Applications |
Length |
35.6 mm |
Leakage Current |
100 μA dc |
Maximum Operating Temperature |
+80°C |
Contact Configuration |
SPST |
Terminal Type |
Quick Connect |
Minimum Operating Temperature |
-30°C |
Dimension |
35.6x21.1x14.3 mm |
Relay Type |
Solid State Relay |
Output Device |
MOSFET |
Switch Type |
DC |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
27 V DC |
Minimum Load Current |
150 mA |
Minimum Control Voltage |
21 V DC |
Maximum Turn On Time |
1 ms |
Control Voltage Range |
21 to 27 V DC |
Maximum Load Voltage |
100 V DC |
Minimum Load Voltage |
3 V DC |
Product Code |
7406644 |
Pack of |
1 Pc |
Manufacturer Part Number |
EL100D10-24 |
Standards Met |
CE, cURus |
