| Load Voltage | 24 to 280 V AC |
| Type of Product | Solid State Relay |
| Height | 14.3 mm |
| Depth | 21.1 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
24 to 280 V AC |
Type of Product |
Solid State Relay |
Height |
14.3 mm |
Depth |
21.1 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
Panel Mount |
Series |
EL |
Maximum Load Current |
20 A |
Country of Origin |
Mexico |
Length |
35.6 mm |
Leakage Current |
0.1 mA RMS |
Maximum Operating Temperature |
+80°C |
Contact Configuration |
SPST |
Terminal Type |
Quick Connect |
Minimum Operating Temperature |
-30°C |
Dimension |
35.6x21.1x14.3 mm |
Switch Type |
Zero Cross |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
27 V DC |
Minimum Load Current |
250 mA |
Minimum Control Voltage |
21 V DC |
Maximum Turn On Time |
1/2 cycle |
Control Voltage Range |
21 to 27 V DC |
Maximum Load Voltage |
280 V AC |
Minimum Load Voltage |
24 V AC |
Product Code |
7406626 |
Pack of |
1 Pc |
Manufacturer Part Number |
EL240A20-24 |
