| Load Voltage | 24 to 280 V AC |
| Type of Product | Solid State Interface Relay |
| Height | 83.7 mm |
| Depth | 11 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
24 to 280 V AC |
Type of Product |
Solid State Interface Relay |
Height |
83.7 mm |
Depth |
11 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
DIN Rail |
Maximum Load Current |
3 A |
Country of Origin |
Mexico |
Length |
87.6 mm |
Leakage Current |
0.1 mA |
Terminal Type |
Screw |
Dimension |
87.6x11x83.7 mm |
Switch Type |
Zero Cross |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
36 V AC |
Minimum Load Current |
150 mA |
Minimum Control Voltage |
18 V AC |
Maximum Turn On Time |
1/2 cycle |
Control Voltage Range |
18 to 36 V AC |
Maximum Load Voltage |
280 V AC |
Minimum Load Voltage |
24 V AC |
Product Code |
7761768 |
Pack of |
1 Pc |
Manufacturer Part Number |
DR24E03 |
