| Power Consumption | About 1.5 VA |
| Control Output | 3A AC240V (resistive load) |
| Type of Product | Super Timer |
| Model No | ST7P-2 AC200V 2H |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Power Consumption |
About 1.5 VA |
Control Output |
3A AC240V (resistive load) |
Type of Product |
Super Timer |
Model No |
ST7P-2 AC200V 2H |
Mass (g) |
About 45 |
Setting Error |
±10% ±0.02s (maximum scale value) |
Return Time |
0.1 seconds or less (including mid-return) |
Monotaro ID |
50266727 |
Operation Mode |
On-delay operation |
Type of Sign |
surface |
Import Country |
Direct Import from Japan |
Vibration Resistance (Destruction) |
10 to 55Hz, double amplitude 0.75mm (1 hour eAC h in 3 axis directions) |
Time |
0.2 to 2h |
Vibration Resistance (Malfunction) |
10 to 55 Hz, double amplitude 0.5 mm (3 axial directions, 10 minutes eAC h) |
Mechanical Durability |
Over 50 million times (no load, switching frequency 1800 times/hour) |
Contact Configuration |
Time limit 2c |
Minimum Applicable Load |
5 VDC, 1 mA (reference value) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Insulation Resistance (MOhm) |
100 or more (at 500V mega) |
Connection Type |
Plug-in type (socket used) |
Allowable Ambient Temperature (℃) |
-10 to 50 (no freezing or condensation) |
Operation Indicator |
Power on/time up...Red LED |
