Ships within 25 days
View
View
View
View
| Power Consumption | For AC: Approximately 10 VA |
| Control Output | AC 240 V 5 Amp (cosΦ=1) |
| Type of Product | Super Timer |
| Model No | MS4SY-AP-NETU |
Power Consumption |
For AC: Approximately 10 VA |
Control Output |
AC 240 V 5 Amp (cosΦ=1) |
Type of Product |
Super Timer |
Model No |
MS4SY-AP-NETU |
Mass (g) |
About 100 |
Withstand Voltage |
Between charging part and non-charging metal part: AC2000V 50 / 60Hz 1 minute/ Between control output and operation circuit: AC2000V 50 / 60Hz 1 minute/ Between discontinuous contact part: AC1000V 50 / 60Hz 1 minute |
Type |
Star-Delta Timer |
Setting Error |
± 5% ± 0.05s (Ratio to maximum scale value) |
Return Time |
0.5s or less |
Monotaro ID |
64021336 |
Import Country |
Direct Import from Japan |
Vibration Resistance (Destruction) |
Double amplitude 0.75mm Frequency 10-55Hz (1 hour eAC h in 3 axes: up / down, left / right, front / bAC k) |
Vibration Resistance (Malfunction) |
Double amplitude 0.5mm Frequency 10-55Hz (10 minutes eAC h in 3 axes of up / down, left / right, front / bAC k) |
Mechanical Durability |
20 million times or more (no-load opening / closing frequency 1800 times / hour) |
Electrical Durability |
80,000 times or more (AC240V 5A resistance opening / closing frequency 1800 times / hour) |
Minimum Applicable Load |
DC5V 100mA (Failure rate 1x<sup>10-7</sup> times) |
Allowable Relative Humidity (%) |
35-85RH (however, no freezing or condensation) |
Allowable Fluctuation of Voltage |
85 to 110%Vn |
Switching time error |
± 20% or less (ratio to set value) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Specifications |
Tropical wetland specifications |
Insulation Resistance (MOhm) |
100 or more (at 500 VDC megger) |
Allowable Ambient Temperature (℃) |
-10-+55 (no freezing or condensation) |
Rated Voltage (V) |
AC 100 to 240 |
