Ships within 19 days
Model No
Maximum Setting Time of Graduation
View
View
View
View
| Power Consumption | (At DC110 V) Before time-up: Approx. 0.4 W, After time-up: Approx. 1.6 W |
| Control Output | Type: Time-delay relay 4c contact output: Opening and closing capacity (resistance load (cosΦ=1)): AC250V 3A, Minimum applicable load: DC1V 1mA (P level, reference value) |
| Protection Class | Ip40 |
| Storage Temperature | -25 to 65 (no condensation or freezing) |
Power Consumption |
(At DC110 V) Before time-up: Approx. 0.4 W, After time-up: Approx. 1.6 W |
Control Output |
Type: Time-delay relay 4c contact output: Opening and closing capacity (resistance load (cosΦ=1)): AC250V 3A, Minimum applicable load: DC1V 1mA (P level, reference value) |
Protection Class |
Ip40 |
Storage Temperature |
-25 to 65 (no condensation or freezing) |
Type of Product |
Solid State Timer |
Model No |
H3Y-4-CBG DC100-110 0.5S |
Mass (g) |
About 50 |
Type |
Monofunction Timer |
Maximum Setting Time of Graduation |
0.5s |
Timed Contacts |
4C |
Monotaro ID |
39073727 |
Adjustable Time |
0.04S to 0.5S |
Power Supply Voltage |
DC100-110 |
Terminal Structure |
Plug-In Terminal |
Series |
H3Y-4 Series |
Import Country |
Direct Import from Japan |
No. Of Pin |
14 |
Operating Temperature Range |
-10 to 50 ℃ (no condensation or freezing) |
Terminal Type |
Plug-In Terminal |
Country of Origin |
China |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Outer Dimensions |
21.5 or less x 63 x 28 or less mm |
Specifications |
Fixed time range |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Operation Ambient Temperature (°C) |
-10 to +50 (no icing) |
