Omron Solid State Timer DC 100 to 110 V, H3YN-4-B DC100-110

Name: Omron Solid State Timer DC 100 to 110 V, H3YN-4-B DC100-110
Brand: Omron
SKU: IND.SOL.638897546
Price: 5191 INR
Availability: InStock

Visit the Omron Store

EMI starts at ₹461/month. No Cost EMI available.

Available offers

Flat ₹400 off on Order above ₹10,000 | Valid for REPEAT Business User

View

Flat ₹800 off on Order above ₹20,000 | Valid for REPEAT Business User

View

Flat ₹200 off on Order above ₹6000 | Valid for REPEAT Business User

View

Flat ₹400 off on Order above ₹10,000 | Valid for NEW Business Users

View

Features

Power Consumption	Relay OFF: Approx. 0.4 W Relay ON: Approx. 1.6 W (at DC 110 V)
Control Output	AC 250 V 3A resistance load (cosΦ = 1), minimum applicable load DC1V 1mA (P level, reference value), contact material: Au clad + Ag alloy
Protection Class	Ip40
Storage Temperature	-25 to +65 ℃ (no freezing)

More Omron Solid State Timers products More Solid State Timers products

Warranty as Per Brand

100% Original Products

Secure Payments

100% Buyer Protection

Top Brands

specifications

Power Consumption	Relay OFF: Approx. 0.4 W Relay ON: Approx. 1.6 W (at DC 110 V)
Control Output	AC 250 V 3A resistance load (cosΦ = 1), minimum applicable load DC1V 1mA (P level, reference value), contact material: Au clad + Ag alloy
Protection Class	Ip40
Storage Temperature	-25 to +65 ℃ (no freezing)
Type of Product	Solid State Timer
Model No	H3YN-4-B DC100-110
Mass (g)	About 50
Influence of Voltage	± 2% or less (at maximum scale time)
Withstand Voltage	AC2000V 50/60Hz 1min (between conductive terminals and exposed non-current metal parts, excluding terminal screws) / AC2000V 50/60Hz 1min (between operation power circuit and control output) / AC2000V 50/60Hz 1min (different polarity contacts) (between 2 pole type)/AC1500V 50/60Hz 1min (between contacts of different poles, 4 pole type)/AC1000V 50/60Hz 1min (between discontinuous contacts)
Type	Multi Timer
Shock Resistance	1000 m/s² 6 directions 3 times each
Timed Contacts	4C
Monotaro ID	24413612
Adjustable Time	0.1 s to 10 min (1 range, 10 s, 1 min, 10 min 4 range switching)
Power Supply Voltage	DC 100 to 110 V
Import Country	Direct Import from Japan
Vibration Resistance (Destruction)	10 to 55 Hz, single amplitude 0.75 mm, 3 directions, 1h each
Country of Origin	CHINA
Name of Manufacturer/Packer/Importer	Omron Corporation
Outer Dimensions	21.5 or less x 63 x 28 or less mm
Specifications	4-hour range multi
Insulation Resistance (MOhm)	100 or more (measured with DC500V mega)
Operation Ambient Temperature (°C)	-10 to +55 (no freezing)
