| Power Consumption | 1.8 VA (at 230 V AC) |
| Control Output | AC 250 V 3A resistive load (cosΦ=1)/Minimum applicable load DC1V 1mA (P level, reference value)/Contact material: Au clad + Ag alloy |
| Protection Class | Ip40 |
| Storage Temperature | -25 to 65℃ (no condensation or freezing) |
Power Consumption |
1.8 VA (at 230 V AC) |
Control Output |
AC 250 V 3A resistive load (cosΦ=1)/Minimum applicable load DC1V 1mA (P level, reference value)/Contact material: Au clad + Ag alloy |
Protection Class |
Ip40 |
Storage Temperature |
-25 to 65℃ (no condensation or freezing) |
Type of Product |
Solid State Timer |
Model No |
H3Y-4-0-AC200-230-1S |
Mass (g) |
About 50 |
Influence of Voltage |
± 2% or less (at maximum scale time) |
Type |
Monofunction timer |
Maximum Setting Time of Graduation |
1S |
Timed Contacts |
4C |
Monotaro ID |
46623464 |
Adjustable Time |
0.1S to 1S |
Power Supply Voltage |
AC 200 to 230 V 50/60 Hz |
Terminal Structure |
Printed Circuit Board Terminal |
Import Country |
Direct Import from Japan |
Operating Temperature Range |
-10 to 50℃ (no condensation or freezing) |
Terminal Type |
Printed Circuit Board Terminal |
Country of Origin |
INDONESIA |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Outer Dimensions |
21.5 or less x 60.7 x 28 or less mm |
Specifications |
Fixed time range |
Insulation Resistance (MOhm) |
100 or more (measured with DC500V mega) |
Operation Ambient Temperature (°C) |
-10 to +50 (no icing) |
Remark |
Confirm Delivery Date Each Time |
