| Power Consumption | Relay OFF: Approx. 0.4 W Relay ON: Approx. 1.6 W (at DC 125 V) |
| Control Output | AC 250 V 3A resistance load (cosΦ = 1), minimum applicable load DC1V 1mA (P level, reference value), contact material: Au clad + Ag alloy |
| Protection Class | Ip40 |
| Storage Temperature | -25 to +65 ℃ (no freezing) |
Power Consumption |
Relay OFF: Approx. 0.4 W Relay ON: Approx. 1.6 W (at DC 125 V) |
Control Output |
AC 250 V 3A resistance load (cosΦ = 1), minimum applicable load DC1V 1mA (P level, reference value), contact material: Au clad + Ag alloy |
Protection Class |
Ip40 |
Storage Temperature |
-25 to +65 ℃ (no freezing) |
Type of Product |
Solid State Timer |
Model No |
H3YN-41-B DC125 |
Mass (g) |
About 50 |
Influence of Voltage |
± 2% or less (at maximum scale time) |
Withstand Voltage |
AC2000V 50/60Hz 1min (between conductive terminals and exposed non-current metal parts, excluding terminal screws) / AC2000V 50/60Hz 1min (between operation power circuit and control output) / AC2000V 50/60Hz 1min (different polarity contacts) (between 2 pole type)/AC1500V 50/60Hz 1min (between contacts of different poles, 4 pole type)/AC1000V 50/60Hz 1min (between discontinuous contacts) |
Type |
Multi Timer |
Shock Resistance |
1000 m/s² 6 directions 3 times each |
Timed Contacts |
4C |
Monotaro ID |
24413515 |
Adjustable Time |
0.1 min to 10 h (4 range switching of 1 min, 10 min, 1 h, 10 h) |
Power Supply Voltage |
DC 125 V |
Import Country |
Direct Import from Japan |
Vibration Resistance (Destruction) |
10 to 55 Hz, single amplitude 0.75 mm, 3 directions, 1h each |
Country of Origin |
CHINA |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Outer Dimensions |
21.5 or less x 63 x 28 or less mm |
Specifications |
4-hour range multi |
Insulation Resistance (MOhm) |
100 or more (measured with DC500V mega) |
Operation Ambient Temperature (°C) |
-10 to +55 (no freezing) |
