| Type of Product | Engine Mechanical Hanger |
| Suitable For | It corresponds to the engine of the ordinary car from the light car of the FF car. <br> (Excluding fenders and strut towers, models without front support mounting bolts, trucks, and 1BOX) <br> Applicable details Engine mass: Maximum working load = 2450N [250kgf] <br> Car width: Bridge maximum slide width = 1550mm <br> Engine room length: Maximum foot slide width = 810mm <br> Engine room recess width: Slide bar variable angle = 32 ° (one side) <br> Engine room height difference: Height adjustment foot expansion / contraction length = 50mm <br> Fender tilt angle: within 20 seconds Maximum set point bolt diameter: 17.5mm <br> Maximum set bolt height: 20mm |
| Country of Origin | JAPAN |
| Name of Manufacturer/Packer/Importer | Kyoto Machine Tools Co., Ltd. |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Engine Mechanical Hanger |
Suitable For |
It corresponds to the engine of the ordinary car from the light car of the FF car. <br> (Excluding fenders and strut towers, models without front support mounting bolts, trucks, and 1BOX) <br> Applicable details Engine mass: Maximum working load = 2450N [250kgf] <br> Car width: Bridge maximum slide width = 1550mm <br> Engine room length: Maximum foot slide width = 810mm <br> Engine room recess width: Slide bar variable angle = 32 ° (one side) <br> Engine room height difference: Height adjustment foot expansion / contraction length = 50mm <br> Fender tilt angle: within 20 seconds Maximum set point bolt diameter: 17.5mm <br> Maximum set bolt height: 20mm |
Country of Origin |
JAPAN |
Name of Manufacturer/Packer/Importer |
Kyoto Machine Tools Co., Ltd. |
Monotaro ID |
7108367 |
Manufacturer Part Number |
AE901 |
Trusco Part No. |
117-7051 |
Mass (Kg) |
16 (winches: 6) |
