Ships within 25 days
View
View
View
View
| Type of Product | Roller Bearing for Sheave NAS |
| Model No | NAS5019ZZNR |
| Material | High Carbon Chromium Steel |
| Monotaro ID | 38304454 |
Type of Product |
Roller Bearing for Sheave NAS |
Model No |
NAS5019ZZNR |
Material |
High Carbon Chromium Steel |
Monotaro ID |
38304454 |
Rolling element material |
High carbon chromium bearing steel |
Outer Diameter |
145 mm |
Inner Diameter |
95 mm |
Load direction |
Radial |
JIS grade |
0 |
No. of Track Trains |
Double row |
Race ring shape |
Cylindrical roller bearing |
Basic static load rating Co (N) |
562000 |
Basic dynamic load rating C (N) |
312000 |
Outer ring type |
With retaining ring |
Shield Shape |
With both shields |
Width B (mm) |
67 |
Width C (mm) |
66 |
Mass (Kg) |
3.9 |
Dimension C1 (mm) |
54 |
Dimension d2 (Φmm) |
150.4 |
Dimensions F (mm) |
2.5 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Nippon Thompson Co., Ltd. |
Dimension J (mm) |
114 |
Allowable Rotation Speed (min-1 [rpm]) |
1100 |
