| Type of Product | Plummer Block Split Type SN6 Standard Type |
| Model No | SN611L1 |
| Monotaro ID | 41103877 |
| Lubrication | Standard grease nipple and drain plug are attached |
Type of Product |
Plummer Block Split Type SN6 Standard Type |
Model No |
SN611L1 |
Monotaro ID |
41103877 |
Lubrication |
Standard grease nipple and drain plug are attached |
Type |
Tapered bore bearing application type |
Dimensions D (mm) |
120 |
Mass (Kg) |
5.8 Kg |
Dimensions g (mm) |
53 |
Shaft diameter d1 (Φmm) |
50 |
Dimensions H (mm) |
80 |
Dimensions A (mm) |
120 |
Dimension N1 (mm) |
18 |
Number |
(Inner diameter number of the receiving shaft) 11 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Dimension L (mm) |
275 |
Dimension T |
M12 |
Dimension H1 |
30 mm |
Dimension S |
M16 |
Nominal No. |
SC611, (Rubber seal) ZF11 |
Dimension n (mm) |
18 |
Dimension J (mm) |
230 |
Dimension H2 |
150 mm |
Dimension A1 |
80 mm |
