| Type of Product | Plummer Block Split Type SN5 Standard Type |
| Model No | SN530L1 |
| Monotaro ID | 41103597 |
| Lubrication | Standard grease nipple and drain plug are attached |
Type of Product |
Plummer Block Split Type SN5 Standard Type |
Model No |
SN530L1 |
Monotaro ID |
41103597 |
Lubrication |
Standard grease nipple and drain plug are attached |
Type |
Tapered bore bearing application type |
Dimensions D (mm) |
270 |
Mass (Kg) |
42 Kg |
Dimensions g (mm) |
106 |
Shaft diameter d1 (Φmm) |
135 |
Dimensions H (mm) |
160 |
Dimensions A (mm) |
220 |
Dimension N1 (mm) |
42 |
Number |
(Inner bore number of shaft used) 30 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Dimension L (mm) |
530 |
Dimension T |
M24 |
Dimension H1 |
60 mm |
Dimension S |
M30 |
Nominal No. |
SC530, (Rubber seal) ZF30 |
Dimension n (mm) |
33 |
Dimension J (mm) |
450 |
Dimension H2 |
325 mm |
Dimension A1 |
160 mm |
