| Type of Product | Plummer Block Split Type SN6 Standard Type |
| Model No | S622L1 |
| Monotaro ID | 41104175 |
| Lubrication | Standard grease nipple and drain plug are attached |
Type of Product |
Plummer Block Split Type SN6 Standard Type |
Model No |
S622L1 |
Monotaro ID |
41104175 |
Lubrication |
Standard grease nipple and drain plug are attached |
Type |
Tapered bore bearing application type |
Dimensions D (mm) |
240 |
Mass (Kg) |
38 Kg |
Dimensions g (mm) |
90 |
Shaft diameter d1 (Φmm) |
100 |
Dimensions H (mm) |
150 |
Dimensions A (mm) |
190 |
Dimension N1 (mm) |
28 |
Number |
(Inner diameter of the receiving shaft) 22 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Dimension L (mm) |
460 |
Dimension T |
M24 |
Dimension H1 |
40 mm |
Dimension S |
M24 |
Nominal No. |
SC622, (Rubber seal) ZF22 |
Dimension n (mm) |
28 |
Dimension J (mm) |
390 |
Dimension H2 |
0 mm |
Dimension A1 |
130 mm |
