| Type of Product | Plummer Block Split Type SN30 Standard Type |
| Model No | SN3024L1 |
| Monotaro ID | 41104412 |
| Lubrication | Standard grease nipple and drain plug are attached |
Type of Product |
Plummer Block Split Type SN30 Standard Type |
Model No |
SN3024L1 |
Monotaro ID |
41104412 |
Lubrication |
Standard grease nipple and drain plug are attached |
Type |
Tapered bore bearing application type |
Dimensions D (mm) |
180 |
Mass (Kg) |
17 Kg |
Dimensions g (mm) |
56 |
Shaft diameter d1 (Φmm) |
110 |
Dimensions H (mm) |
112 |
Dimensions A (mm) |
150 |
Dimension N1 (mm) |
32 |
Number |
(Inner diameter number of the receiving shaft) 24 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Dimension L (mm) |
380 |
Dimension T |
M20 |
Dimension H1 |
40 mm |
Dimension S |
M24 |
Nominal No. |
SN3024, (rubber seal) ZF24 |
Dimension n (mm) |
26 |
Dimension J (mm) |
320 |
Dimension H2 |
217 mm |
Dimension A1 |
110 mm |
