| Type of Product | Plummer Block Split Type SN5 Standard Type |
| Model No | SN522L5 |
| Monotaro ID | 41103466 |
| Lubrication | Comes with standard oil plug and drain plug |
Type of Product |
Plummer Block Split Type SN5 Standard Type |
Model No |
SN522L5 |
Monotaro ID |
41103466 |
Lubrication |
Comes with standard oil plug and drain plug |
Type |
Tapered bore bearing application type |
Dimensions D (mm) |
200 |
Mass (Kg) |
20 Kg |
Dimensions g (mm) |
80 |
Shaft diameter d1 (Φmm) |
100 |
Dimensions H (mm) |
125 |
Dimensions A (mm) |
175 |
Dimension N1 (mm) |
32 |
Number |
(Inner diameter of the receiving shaft) 22 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Dimension L (mm) |
410 |
Dimension T |
M20 |
Dimension H1 |
45 mm |
Dimension S |
M24 |
Nominal No. |
SC522, (Rubber seal) ZF22 |
Dimension n (mm) |
26 |
Dimension J (mm) |
350 |
Dimension H2 |
240 mm |
Dimension A1 |
120 mm |
