| Type of Product | Plummer Block Split Type Sd5 Standard Type |
| Model No | SD534L1 |
| Monotaro ID | 41106765 |
| Lubrication | Standard grease nipple and drain plug are attached |
Type of Product |
Plummer Block Split Type Sd5 Standard Type |
Model No |
SD534L1 |
Monotaro ID |
41106765 |
Lubrication |
Standard grease nipple and drain plug are attached |
Type |
Tapered bore bearing application type |
Dimensions D (mm) |
310 |
Mass (Kg) |
94 Kg |
Dimensions g (mm) |
96 |
Shaft diameter d1 (Φmm) |
150 |
Dimensions H (mm) |
180 |
Dimensions A (mm) |
270 |
Dimension N1 (mm) |
52 |
Number |
(Inner diameter number of receiving shaft) 34 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Dimension L (mm) |
620 |
Dimension T |
M24 |
Dimension H1 |
60 mm |
Dimension S |
M30 |
Nominal No. |
SD534, (Rubber seal) ZF34 |
Dimension n (mm) |
32 |
Dimension J (mm) |
510 |
Dimension H2 |
360 mm |
Dimension A1 |
230 mm |
Dimension J1 (mm) |
140 |
