| Type of Product | Plummer Block Split Type SNZ2 Different Diameter |
| Model No | SNZ216L5 |
| Monotaro ID | 41105934 |
| Lubrication | Comes with standard oil plug and drain plug |
Type of Product |
Plummer Block Split Type SNZ2 Different Diameter |
Model No |
SNZ216L5 |
Monotaro ID |
41105934 |
Lubrication |
Comes with standard oil plug and drain plug |
Type |
Cylindrical bore bearing applicable type |
Dimensions D (mm) |
140 |
Mass (Kg) |
12 Kg |
Dimensions g (mm) |
43 |
Shaft diameter d1 (Φmm) |
80 |
Dimensions H (mm) |
95 |
Dimensions A (mm) |
120 |
Dimension N1 (mm) |
27 |
Number |
(Inner bore number of the receiving shaft) 16 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Dimension L (mm) |
315 |
Dimension T |
M16 |
Dimension H1 |
32 mm |
Shaft Outer Diameter |
90 mm |
Dimension S |
M20 |
Nominal No. |
SNZ216, (Rubber seal) d2 side / ZF16: d3 side / ZF20 |
Dimension n (mm) |
22 |
Dimension J (mm) |
260 |
Dimension H2 |
175 mm |
Dimension A1 |
90 mm |
