Ships within 19 days
View
View
View
View
| Type of Product | Plummer Block Split Type SNZ3 Different Diameter |
| Model No | SNZ308L5 |
| Monotaro ID | 41106354 |
| Lubrication | Comes with standard oil plug and drain plug |
Type of Product |
Plummer Block Split Type SNZ3 Different Diameter |
Model No |
SNZ308L5 |
Monotaro ID |
41106354 |
Lubrication |
Comes with standard oil plug and drain plug |
Type |
Cylindrical bore bearing applicable type |
Dimensions D (mm) |
90 |
Mass (Kg) |
3.5 Kg |
Dimensions g (mm) |
43 |
Shaft diameter d1 (Φmm) |
40 |
Dimensions H (mm) |
60 |
Dimensions A (mm) |
95 |
Dimension N1 (mm) |
20 |
Number |
(Inner bore number of shaft used) 08 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Dimension L (mm) |
205 |
Dimension T |
M10 |
Dimension H1 |
25 mm |
Shaft Outer Diameter |
50 mm |
Dimension S |
M12 |
Nominal No. |
SNZ308, (Rubber seal) d2 side / ZF8: d3 side / ZF11 |
Dimension n (mm) |
15 |
Dimension J (mm) |
170 |
Dimension H2 |
115 mm |
Dimension A1 |
60 mm |
