| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | TAKIGEN MFG CO., LTD |
| Type of Product | Plane Swing Handle |
| Model No | A-481N-5-2 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
TAKIGEN MFG CO., LTD |
Type of Product |
Plane Swing Handle |
Model No |
A-481N-5-2 |
Material |
Zinc Alloy (ZDC) |
Weight |
420 g |
Dimensions L1 (mm) |
110 |
Dimensions l2 (mm) |
17 |
Monotaro ID |
61104812 |
Included Components |
Screw Set, Special Clasp, Mounting Plate |
Dimensions H2 (mm) |
26 |
Dimension H3 (mm) |
4.5 |
Dimensions W2 (mm) |
26 |
Dimension W3 (mm) |
24 |
Dimensions H1 (mm) |
49 |
Dimension H4 (mm) |
25 |
Dimensions W1 (mm) |
35 |
Dimension L3 (mm) |
102 |
Suitable Thickness of Workpiece (mm) |
0 to 2.3 |
Dimensions l4 (mm) |
62 |
Dimensions l5 (mm) |
22 |
Dimension L6 |
15 mm |
Dimensions T (mm) |
2.2999999999999998 |
Dimension L7 |
103 |
Import Country |
Direct Import from Japan |
