| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | TAKIGEN MFG CO., LTD |
| Type of Product | Solenoid Lock |
| Model No | LE-30-10 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
TAKIGEN MFG CO., LTD |
Type of Product |
Solenoid Lock |
Model No |
LE-30-10 |
TAKIGEN Code |
50114 |
Monotaro ID |
61130213 |
Key |
Lock for emergency release: T750 |
Power Consumption (W) |
9.5 |
Switch Type |
Rating (Resistive Load): 125 VAC, 1 A / 30 VDC, 0.5 A |
Operating Ambient Temperature |
-5 to 40° (No Freezing) |
Current Consumption (mA) |
396 |
Ambient Humidity (% RH) |
85 or less (No Condensation) |
Energization Rate |
100% (Continuous Rating) |
Horizontal Load (N) |
Latch Pull-In Force: 2.94 |
Push Output (N) |
Latch/Horizontal: 3.72 |
Rated Voltage (V) |
DC24±5% |
Import Country |
Direct Import from Japan |
