| Type of Product | Double Row Cylindrical Roller Follower NURT R (Spherical Outer Ring) |
| Model No | NURT35-1R |
| Inner Diameter | 35 mm |
| Country of Origin | Japan |
Type of Product |
Double Row Cylindrical Roller Follower NURT R (Spherical Outer Ring) |
Model No |
NURT35-1R |
Inner Diameter |
35 mm |
Country of Origin |
Japan |
Chamfer Dimension r1 (mm) |
0.6 |
Monotaro ID |
10302503 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Nippon Thompson Co., Ltd. |
Type |
NURT-R |
Specifications |
1N≒0.102kgf |
Mass (g) |
840 g |
Dimensions B (mm) |
29 |
Chamfer Dimension r (mm) |
1 |
Dimensions D (mm) |
35 |
Outer Diameter (Φmm) |
80 |
Dimensions C (mm) |
28 |
Basic Dynamic Load Rating (N) |
63900 |
Basic Static Load Rating (N) |
88800 |
Dimensions A (mm) |
44 |
Maximum allowable static load (N) |
88800 |
