| Type of Product | Non-Separable Type Roller Follower NARTVR (Shielded Type, Full Roller, Spherical Outer Ring) |
| Model No | NART5VR |
| Inner Diameter | 5 mm |
| Country of Origin | Japan |
Type of Product |
Non-Separable Type Roller Follower NARTVR (Shielded Type, Full Roller, Spherical Outer Ring) |
Model No |
NART5VR |
Inner Diameter |
5 mm |
Country of Origin |
Japan |
Monotaro ID |
10301977 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Nippon Thompson Co., Ltd. |
Type |
NART-VR |
Specifications |
1N≒0.102kgf |
Mass (g) |
15.1 g |
Dimensions B (mm) |
12 |
Dimensions D (mm) |
5 |
Outer Diameter (Φmm) |
16 |
Dimensions C (mm) |
11 |
Basic Dynamic Load Rating (N) |
6810 |
Basic Static Load Rating (N) |
8370 |
Dimensions A (mm) |
12 |
Maximum allowable static load (N) |
7310 |
