| Type of Product | Non-Separable Roller Follower NARTR (Shielded Type, With Cage, Spherical Outer Ring) |
| Model No | NART20R |
| Inner Diameter | 20 mm |
| Country of Origin | Japan |
Type of Product |
Non-Separable Roller Follower NARTR (Shielded Type, With Cage, Spherical Outer Ring) |
Model No |
NART20R |
Inner Diameter |
20 mm |
Country of Origin |
Japan |
Monotaro ID |
10301907 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Nippon Thompson Co., Ltd. |
Type |
NART-R |
Specifications |
1N≒0.102kgf |
Mass (g) |
250 g |
Dimensions B (mm) |
25 |
Dimensions D (mm) |
20 |
Outer Diameter (Φmm) |
47 |
Dimensions C (mm) |
24 |
Basic Dynamic Load Rating (N) |
23000 |
Basic Static Load Rating (N) |
30700 |
Dimensions A (mm) |
38 |
Maximum allowable static load (N) |
30700 |
