| Type of Product | Separate Type Roller Follower NASTR (Open Type, With Inner Ring, Spherical Outer Ring) |
| Model No | NAST6R |
| Inner Diameter | 6 mm |
| Country of Origin | Japan |
Type of Product |
Separate Type Roller Follower NASTR (Open Type, With Inner Ring, Spherical Outer Ring) |
Model No |
NAST6R |
Inner Diameter |
6 mm |
Country of Origin |
Japan |
Chamfer Dimension r1 (mm) |
0.3 |
Monotaro ID |
10301024 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Nippon Thompson Co., Ltd. |
Type |
NAST-R |
Specifications |
1N≒0.102kgf |
Mass (g) |
17.8 g |
Nominal No. |
6 |
Dimensions B (mm) |
10 |
Chamfer Dimension r (mm) |
0.3 |
Dimensions D (mm) |
6 |
Outer Diameter (Φmm) |
19 |
Dimensions C (mm) |
9.8000000000000007 |
Basic Dynamic Load Rating (N) |
4160 |
Basic Static Load Rating (N) |
4550 |
Dimension Fw (mm) |
10 |
Inner ring |
With inner ring |
