| Type of Product | Spherical Roller Bearing Cylindrical Bore 22300 Series |
| Material | High Carbon Chromium Bearing Steel |
| Model No | 22320EAE4 |
| Country of Origin | Japan |
Type of Product |
Spherical Roller Bearing Cylindrical Bore 22300 Series |
Material |
High Carbon Chromium Bearing Steel |
Model No |
22320EAE4 |
Country of Origin |
Japan |
Load direction |
Radial |
Rolling element material |
High carbon chromium bearing steel |
JIS grade |
0 |
Outer ring type |
Flat |
Inner Diameter d (Φmm) |
100 |
No. of Track Trains |
Single row |
Shield Shape |
Open type |
Race ring shape |
Spherical roller bearing |
Width B (mm) |
73 |
Monotaro ID |
32997413 |
Outer Diameter D (Φmm) |
215 |
Import Country |
Direct Import from Japan |
Mass (Kg) |
12.7 Kg |
Name of Manufacturer/Packer/Importer |
NSK Ltd. |
Mass (g) |
12700 |
Chamfer Dimension r (mm) |
3 (minimum) |
Allowable Speed (min-1[r.p.m]) Grease Lubrication |
2000 |
Allowable Speed (min-1 [r.p.m]) Oil Lubrication |
2600 |
Basic load rating Cor (N) |
930000 |
Basic load rating Cr (N) |
860000 |
