| Phase | 5-Phase |
| Motor Length (mm) | 51.5 |
| Model No | FAF525S |
| Type of Product | Stepping System Set |
Phase |
5-Phase |
Motor Length (mm) |
51.5 |
Model No |
FAF525S |
Type of Product |
Stepping System Set |
Country of Origin |
Japan |
Shaft |
Uniaxial |
Name of Manufacturer/Packer/Importer |
Sanyo Electric Co., Ltd. |
Monotaro ID |
56307527 |
Power Supply Voltage (V) |
(Driver) DC24 / 48 |
Outer Dimensions (mm) |
(Driver) 118x28x75 |
Product Type |
Stepping motor |
Import Country |
Direct Import from Japan |
Size (mm) |
Φ28 |
Type of Sign |
Flange Mounting |
Maximum Static Torque |
0.078 Nm or more |
Rated Current (A/Phase) |
0.75 |
Standard Step Angle |
0.72° |
Set Contents |
Motor (SH5285-7241), driver (F5PAE140P100), cable with connector (for power supply: FC3P0010A, for input / output signals: FC3S0010A, for motor: FC3M0010Ax1m each) |
