| Phase | 5-Phase |
| Motor Length (mm) | 148 |
| Model No | FA512M861S-HX100 |
| Voltage | AC 100 V |
Phase |
5-Phase |
Motor Length (mm) |
148 |
Model No |
FA512M861S-HX100 |
Voltage |
AC 100 V |
Type of Product |
Microstep Motor |
Country of Origin |
Japan |
Shaft |
Uniaxial |
Name of Manufacturer/Packer/Importer |
Sanyo Electric Co., Ltd. |
Monotaro ID |
56312262 |
Power Supply Voltage (V) |
(Driver) Single phase AC100 to 200 |
Outer Dimensions (mm) |
(Driver) 40x160x120 |
Product Type |
Stepping motor |
Import Country |
Direct Import from Japan |
Size (mm) |
Φ86 |
Type of Sign |
Flange Mounting |
Model Name |
Model with harmonic gear |
Rated Current (A/Phase) |
0.75 |
Standard Step Angle |
0.0072° |
Set Contents |
Motor (SM5861-72HXM40), driver (F5PAA075P100), power supply connector CN1 (FC6P0000A), I / O signal cable CN3: 1m product (FC5S0010A) |
Cable length (mm) |
500 |
Belt-End Finish |
Lead wire with connector |
Applicable gear head |
90 mm |
Driver Type |
Microstep |
Allowable Torque (Nm) |
40, (Instantaneous tolerance) 59 |
Reduction Ratio |
100 |
