| Model No | CS-NPJ50-600SP |
| Type of Product | SPD |
| Impulse Current | 20 kA /C2(8 kA /20μs), 2.5 kA /D1(10 kA /350μs) |
| Country of Origin | Japan |
Model No |
CS-NPJ50-600SP |
Type of Product |
SPD |
Impulse Current |
20 kA /C2(8 kA /20μs), 2.5 kA /D1(10 kA /350μs) |
Country of Origin |
Japan |
Monotaro ID |
83273269 |
Connector |
N type |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Otowa Electric Industry Co., Ltd. |
Voltage Protection Level |
1500 or less V |
VSWR |
DC to 2.0GHz |
Maximum Continuous Operating Voltage |
DC430 V |
Impedance (Ω) |
50 |
Insertion loss (dB) |
0.2 or less (DC-2.0GHz) |
Power (W) |
200 (maximum) |
RoHS Directive |
Correspondence |
Applicable Transmission Band |
DC to 2.0GHz |
