Ships within 25 days
View
View
View
View
| Type of Product | High Pressure Air Load Switch |
| Monotaro ID | 50213441 |
| Mass (g) | 12 Kg |
| Rated Frequency (Hz) | 50/60 |
Type of Product |
High Pressure Air Load Switch |
Monotaro ID |
50213441 |
Mass (g) |
12 Kg |
Rated Frequency (Hz) |
50/60 |
Model No |
LB-6/400 |
Country of Origin |
Japan |
Mechanical Life |
1000 times |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Withstand Voltage |
(Rating) 60000V |
Rated Voltage (V) |
7200/3600 |
Mounting Angle |
Variable (can be combined with R290 and R293) |
Withstand Current |
12.5 kA (1s) |
Recharging Current |
10 Amp (10 times) |
Current |
50 Amp (200 times) |
Load Current (Amp) |
400 (200 times) |
Rated Input Current (A) |
(Short circuit input, peak value) A31.5 |
Left Mounting of the Handle |
Possible (combined with LB-LH) |
Conformed Standard |
JIS C 4605 |
Mechanism |
Fast-Cut Mechanism |
Rated Current (A) |
400 |
Excitation Current |
20 Amp (10 times) |
