| Type of Product | Relay Adapter |
| Monotaro ID | 34997934 |
| Material | (Shell, Body, Contact) Copper alloy / Outer conductor-Ag, Center contact-Ni plating, (Insulator) Ethylene tetrafluoride, (Gasket) Silicon rubber |
| Model No | BNC-A-JJ-Ni-CF |
Type of Product |
Relay Adapter |
Monotaro ID |
34997934 |
Material |
(Shell, Body, Contact) Copper alloy / Outer conductor-Ag, Center contact-Ni plating, (Insulator) Ethylene tetrafluoride, (Gasket) Silicon rubber |
Model No |
BNC-A-JJ-Ni-CF |
Country of Origin |
Japan |
Connection Type |
Bayonet lock system |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Fujikura (formerly DDK/Daiichi Electronics Industries) |
Withstand Voltage |
1500 V AC (RMS) for 1 minute |
Insulation Resistance (MOhm) |
1000 or more (DC 500 V) |
Contact Resistance (ohm) |
3 or less |
Voltage standing wave ratio |
1.3 or less (DC to 2 GHz) |
Characteristic impedance (Ω) |
50 |
