| Type of Product | Buzzer (Round body type Φ16) High volume type (Rectangular) B2BJ |
| Monotaro ID | 46483717 |
| Mass (g) | About 12 |
| Type | High volume Type With Led |
Type of Product |
Buzzer (Round body type Φ16) High volume type (Rectangular) B2BJ |
Monotaro ID |
46483717 |
Mass (g) |
About 12 |
Type |
High volume Type With Led |
Color |
Black |
Inrush current (A) |
Up to 1 |
Shape |
Rectangle |
Model No |
M2BJ-BH06E |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Protection Class |
Ip40 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10 to 55 (no freezing or condensation) |
Current Consumption (mA) |
DC max 50, AC max 100 |
Insulation Resistance (MOhm) |
100 or more (between each terminal and ground) |
Storage Temperature |
-25 To 65 ℃ (No Freezing Or Condensation) |
Specifications |
Confirm Delivery Date Each Time |
Applicable Voltage (V) |
AC/DC6 |
Tone |
When inserting the short circuit bar in direction A: Intermittent beep-beep-beep When inserting the short circuit bar in direction B (when removing the short circuit bar): Intermittent beep-beep |
Durability |
1000h or more |
Buzzer Sound |
When the shorting piece A is inserted: Intermittent sound (pico / pico / pico), When the shorting piece B is inserted (when the short piece is removed): Continuous sound (P / P) |
Frequency (kHz) |
(Drive) 3±0.5 |
Sound Pressure Level (dB) |
TYP.70 to 95 (horn) (adjustable range) (A range) (adjustable range) (rated voltage, distance 0.1m, A range) |
Sound Pressure |
Distance 0.1m, Rated voltage: Typ. 70 to 95 dB (horn) (adjustable range) (A range) |
