Ships within 25 days
View
View
View
View
| Type of Product | Smart Package |
| Monotaro ID | 46452691 |
| Type | Discriminating displacement sensor |
| Material | Case: Polybutylene terephthalate/Cover: Polycarbonate |
Type of Product |
Smart Package |
Monotaro ID |
46452691 |
Type |
Discriminating displacement sensor |
Material |
Case: Polybutylene terephthalate/Cover: Polycarbonate |
Model No |
ZX-SAM12 |
Country of Origin |
JAPAN |
Connection Type |
Pre-wired model |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Output |
NPN open collector output/DC30V/25mAmin., residual voltage 1.2V or less |
Power Supply Voltage |
DC 12-24 V ± 10% Ripple (pp) 10% or less |
Length (m) |
2 |
Input Specifications |
0V short circuit/or 1.5V or less when ON, open when OFF (leakage current 0.1 mA or less) |
Current Consumption (A) |
0.070 or less when power supply voltage is DC 12 V |
Output Signal |
Operation result PASS output, operation result NG output gate output |
Input Signal |
Reference value setting input, bank switching input (Bank1/2), timing input |
