| Type of Product | Compact Amplifier |
| Monotaro ID | 8585543 |
| Mass (g) | Approx. 20 (packed) |
| Type | Built-in amplifier |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Compact Amplifier |
Monotaro ID |
8585543 |
Mass (g) |
Approx. 20 (packed) |
Type |
Built-in amplifier |
Country of Origin |
Japan |
Connection Type |
M8 connector type |
Case Material |
Polybutylene terephthalate |
Import Country |
Direct Import from Japan |
Protection Class |
IEC standard IP67 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Manufacturer Part Number |
E3Z-LS68 |
With or Without Indication Lamp |
Included |
Included Components |
Instruction Manual Note: Mounting brackets sold separately |
Cable Length (m) |
- |
Output |
NPN |
Head Shape |
Square |
Operation Ambient Temperature (°C) |
Operating: -25 to 55, Storage: -40 to 70 (with no icing or condensation) |
Current Consumption (mA) |
30 or less |
Ambient Humidity (% RH) |
Operating: 35 to 85, Storage: 35 to 95 (no condensation) |
Control Output |
Load power supply Voltage 26.4 V DC or less, load current 100 mA or less (residual Voltage 1 V or less), open collector output type ( Varies depending on NPN / PNP output model), light-on ON / light-on ON switch switching type |
Light Source (Projection Wavelength) |
Red light emitting diode (680nm) |
Insulation Resistance (MOhm) |
20 or more (at 500 VDC) |
Power Supply Voltage |
DC12-24 ± 10% Ripple (pp) 10% or less |
Setting Range |
20-80mm (white paper 25x25mm) |
Response Time |
Operation / Reset: 1 ms or less |
Detection Method |
Distance setting type |
