| Bore Diameter | 50.8 mm (2 inch) |
| Type of Product | Four-Bolt Flange Unit Bearing |
| Model No | UCTX10-200D1 |
| Seal Type | Contact Seal |
Bore Diameter |
50.8 mm (2 inch) |
Type of Product |
Four-Bolt Flange Unit Bearing |
Model No |
UCTX10-200D1 |
Seal Type |
Contact Seal |
Locking |
Set Screw |
Seal Material |
Nitrile Rubber |
Lubrication |
Relubricatable |
Weight |
Approximately 3.77 kg (8.31 lb) |
Housing Width |
60 mm |
Dynamic Load Rating |
43.50 kN |
Bore Type |
Cylindrical |
Static Load Rating |
29.20 kN |
Housing Material |
Cast Iron |
Outside Diameter |
100 mm |
Cage Material |
Pressed Steel |
Performance |
Medium Duty |
Clearance |
CN |
End Type |
Open |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Mechanical Solutions |
Bearing Type |
Ball Bearing |
Precision |
ISO Class 0 |
Mounting Type |
Square 4-Bolt Flange |
Bearing Number |
UCX10-200D1 |
Ball Material |
Through Hardened Steel |
Maximum Rotational Speed |
2900 RPM |
Operating Temperature |
-40°C to 120°C |
Bearing Width (B) |
55.6 mm |
Bolt Hole Center Distance (J) |
130 mm (5.125 inch) |
Housing Construction |
1 Piece |
Mounting Hole |
4 |
Housing Number |
FX10D1 |
Enclosure |
Flinger Seal (Both Sides) |
Overall Flange Width (L) |
162 mm (6.375 inch) |
