Ships within 25 days
View
View
View
View
| Country of Origin | Japan |
| Race ring shape | Tapered Roller Bearing |
| Outer Diameter D (Φmm) | 62 |
| Width B (mm) | 20 |
Country of Origin |
Japan |
Race ring shape |
Tapered Roller Bearing |
Outer Diameter D (Φmm) |
62 |
Width B (mm) |
20 |
Monotaro ID |
56731806 |
Type of Product |
Tapered Roller Bearing 30000 Series |
Model No |
32206JR |
Working Point a (mm) |
15.9 |
Dimensions C (mm) |
17 |
Dimensions B (mm) |
20 |
Dimensions D (mm) |
30 |
Mass (Kg) |
0.29199999999999998 |
Dimension r1 (mm) |
1 (minimum) |
Coefficient |
(Axial load) Y1 = 1.60, Y0 = 0.88 |
Reference mass (g) |
292 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
JTEKT Corporation |
Inner Diameter (mm) |
30 |
Chamfer Dimension r (mm) |
1(r1=1) |
Basic Rated Load Cor (kN) |
57.9 |
Dimension R |
1 (minimum) mm |
Basic Rated Load Cr (kN) |
63.3 |
Dimension T |
21.25 mm |
Permissible Speed (min-1) Grease Lubrication |
6500 |
RoHS Directive |
Correspondence |
