| Country of Origin | Japan |
| Race ring shape | Tapered Roller Bearing |
| Outer Diameter D (Φmm) | 68 |
| Width B (mm) | 19 |
Country of Origin |
Japan |
Race ring shape |
Tapered Roller Bearing |
Outer Diameter D (Φmm) |
68 |
Width B (mm) |
19 |
Monotaro ID |
22235176 |
Type of Product |
Tapered Roller Bearing 30000 Series |
Model No |
32008JR |
Dimensions C (mm) |
14.5 |
Dimensions B (mm) |
19 |
Dimensions D (mm) |
40 |
Mass (Kg) |
0.28199999999999997 |
Dimension r1 (mm) |
1 |
Working Point Distance a0 (mm) |
15.1 |
Reference mass (g) |
282 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
JTEKT Corporation |
Inner Diameter (mm) |
40 |
Chamfer Dimension r (mm) |
1(r1=1) |
Permissible Speed (min-1) Oil Lubrication |
7400 |
Basic Rated Load Cor (kN) |
71.400000000000006 |
Dimension R |
1 mm |
Basic Rated Load Cr (kN) |
67.2 |
Dimension T |
19 mm |
Permissible Speed (min-1) Grease Lubrication |
5600 |
RoHS Directive |
Correspondence |
