| Width T (mm) | 54.5 |
| Load direction | Radial |
| Outer ring type | Flat |
| Inner Diameter d (Φmm) | 110 |
Width T (mm) |
54.5 |
Load direction |
Radial |
Outer ring type |
Flat |
Inner Diameter d (Φmm) |
110 |
Country of Origin |
Japan |
No. of Track Trains |
Single row |
Shield Shape |
Open type |
Race ring shape |
Tapered roller bearing |
Material |
High Carbon Chromium Bearing Steel |
Outer Diameter D (Φmm) |
240 |
Rolling element material |
High carbon chromium bearing steel |
JIS grade |
0 |
Monotaro ID |
68555347 |
Type of Product |
Tapered Roller Bearings 30300 Type |
Model No |
E30322J |
Mass (g) |
11400 |
Dimensions C (mm) |
42 |
Mass (Kg) |
11.4 Kg |
Basic static load rating Cor (N) |
590000 |
Basic dynamic load rating Cr (N) |
481000 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Fujikoshi Corporation |
Allowable Speed (min-1[r.p.m]) Grease Lubrication |
1600 |
Allowable Speed (min-1 [r.p.m]) Oil Lubrication |
2100 |
Chamfer Dimension r (mm) |
(Inner ring) min.4, (Outer ring) min.3 |
