| Width T (mm) | 32.75 |
| Load direction | Radial |
| Outer ring type | Flat |
| Inner Diameter d (Φmm) | 65 |
Width T (mm) |
32.75 |
Load direction |
Radial |
Outer ring type |
Flat |
Inner Diameter d (Φmm) |
65 |
Country of Origin |
Japan |
No. of Track Trains |
Single row |
Shield Shape |
Open type |
Race ring shape |
Tapered roller bearing |
Material |
High Carbon Chromium Bearing Steel |
Outer Diameter D (Φmm) |
120 |
JIS grade |
0 |
Width B (mm) |
31 |
Monotaro ID |
36910115 |
Type of Product |
Tapered Roller Bearing |
Model No |
32213 |
Contact Angle |
Over 10 ° and below 17 ° |
Thickness t (mm) |
32.75 |
Mass (Kg) |
2 Kg |
Reference mass (g) |
1580 |
Width C (mm) |
27 |
Basic static load rating Cor (N) |
206000 |
Basic dynamic load rating Cr (N) |
159000 |
Operating Temperature Range |
-40 to 120℃ |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Trusco Part No. |
214-2457 |
