Ships within 19 days
View
View
View
View
| Width T (mm) | 23 |
| Load direction | Radial |
| Outer ring type | Flat |
| Inner Diameter d (Φmm) | 65 |
Width T (mm) |
23 |
Load direction |
Radial |
Outer ring type |
Flat |
Inner Diameter d (Φmm) |
65 |
Country of Origin |
Japan |
Shield Shape |
Open type |
Race ring shape |
Tapered roller bearing |
Material |
High Carbon Chromium Bearing Steel |
Outer Diameter D (Φmm) |
100 |
JIS grade |
0 |
Width B (mm) |
23 |
Monotaro ID |
36909984 |
Type of Product |
Tapered Roller Bearing |
Model No |
32013 |
Contact Angle |
Over 10 ° and below 17 ° |
Mass (g) |
630 g |
Dimensions C (mm) |
17.5 |
Thickness t (mm) |
23 |
Reference mass (g) |
630 |
Width C (mm) |
17.5 |
Basic static load rating Cor (N) |
128000 |
Basic dynamic load rating Cr (N) |
83000 |
Operating Temperature Range |
-40 to 120℃ |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Trusco Part No. |
214-2317 |
