| Type of Product | Temperature Sensor |
| Model No | E52-P15AY D=3.2 NETU 1M |
| Operating Temperature Range | 0~180°C (0~100°C for Sleeve Part) |
| Material | (Sheath) SUS316 |
Type of Product |
Temperature Sensor |
Model No |
E52-P15AY D=3.2 NETU 1M |
Operating Temperature Range |
0~180°C (0~100°C for Sleeve Part) |
Material |
(Sheath) SUS316 |
Temperature Range |
-196 to +450°C (In Dry Air) |
Temperature Measurement Range |
-196~450°C |
Monotaro ID |
46782583 |
Terminal Shape |
Exposed-Lead Model (Y Type Crimp Terminal for M3.5) |
Protective Tube Length L (cm) |
15 cm |
Wire Type |
PT100 |
Method |
3 Conductor Type |
JIS Class |
B (B Class) |
Protective Tube Diameter D (Φmm) |
Φ3.2 mm |
Dimensions D (mm) |
8 mm |
Sheath outer diameter (Φmm) |
Φ3.2 mm |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Structure |
Sheath Platinum Resistance Thermometer |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Temperature Measuring Contact |
3 Conductor Type |
Class |
B (B Class) |
