| Type of Product | Regular-Use Type Temperature Sensor |
| Model No | E52-IC20AY-D=6.4-1M |
| Operating Temperature Range | -20 to 70℃ Sleeve section: 0 to 70℃ |
| Material | (Sheath) ASTM316L |
Type of Product |
Regular-Use Type Temperature Sensor |
Model No |
E52-IC20AY-D=6.4-1M |
Operating Temperature Range |
-20 to 70℃ Sleeve section: 0 to 70℃ |
Material |
(Sheath) ASTM316L |
Temperature Measurement Range |
0 to 750℃ (in dry air) |
Monotaro ID |
46673164 |
Terminal Shape |
Exposed-lead model (Y type crimp terminal for M3.5) |
Protective Tube Length L (cm) |
20 |
Wire Type |
J |
Method |
Non-ground type |
Protective Tube Diameter D (Φmm) |
6.4 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Structure |
Sheath type thermocouple |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Temperature Measuring Contact |
Non-ground type |
Class |
2 (0.75 class) |
Lead Wire Length |
1 m |
Dimension L (mm) |
55 |
Wire Used |
Vinyl coating |
Dimension d |
11 mm |
