| Type of Product | Temperature Sensor Low Cost Type |
| Model No | E52-IC6ASY1M |
| Type | Exposed-lead model with spring |
| Material | (Protective tube) SUS304 |
Type of Product |
Temperature Sensor Low Cost Type |
Model No |
E52-IC6ASY1M |
Type |
Exposed-lead model with spring |
Material |
(Protective tube) SUS304 |
Monotaro ID |
66474862 |
Terminal Shape |
Direct lead wire type/Y type crimp terminal |
Temperature Range (℃) |
0 to 350 (in dry air) |
Lead Wire |
Fully glass wool coated conductor (finished outer dimensions 5.1 x 3.0), 4/0.65, 0 to 180°C |
Wire Type |
J |
Method |
Non-ground type |
JIS Class |
2 (0.75 class) |
Protective Tube Diameter D (Φmm) |
4.8 |
Wire Diameter (mm) |
0.65 (single wire) |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Lead Wire Length |
1 m |
Protective Tube Length L (mm) |
65 |
