| Type of Product | Temperature Sensor |
| Model No | E52-IC20C-N D=6.4 |
| Operating Temperature Range | -20~70°C Sleeve Part is 0~70°C |
| Material | (Sheath) ASTM316L |
Type of Product |
Temperature Sensor |
Model No |
E52-IC20C-N D=6.4 |
Operating Temperature Range |
-20~70°C Sleeve Part is 0~70°C |
Material |
(Sheath) ASTM316L |
Temperature Range |
0 to +750°C (In Dry Air) |
Temperature Measurement Range |
0~750°C |
Monotaro ID |
46782522 |
Terminal Shape |
Built-in Terminal Type |
Protective Tube Length L (cm) |
20 cm |
Wire Type |
J |
Method |
Non-ground Type |
JIS Class |
2 (0.75 Class) |
Protective Tube Diameter D (Φmm) |
Φ6.4 mm |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Structure |
Sheath Type Thermocouple |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Temperature Measuring Contact |
Non-ground Type |
Class |
2 (0.75 Class) |
