| Type of Product | Temperature Sensor Ferrule Terminal |
| Model No | E52-CA20AFD=1.6NETU8M |
| Operating Temperature Range | 0-150℃ |
| Monotaro ID | 66473146 |
Type of Product |
Temperature Sensor Ferrule Terminal |
Model No |
E52-CA20AFD=1.6NETU8M |
Operating Temperature Range |
0-150℃ |
Monotaro ID |
66473146 |
Terminal Shape |
Direct lead wire type/ferrule terminal |
Protective Tube Diameter D (Φmm) |
1.6 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Temperature Measuring Contact |
Non-ground type |
Class |
JIS class 2 (0.75 grade) |
Lead Wire Length |
8 mm |
Protective Tube Length L (mm) |
200 |
Specifications |
Sheath type thermocouple ● Lead wire type: Heat resistant ● Material (protection tube): ASTM316L ● Protection tube structure: Sheath type ● Material (lead wire coating): Glass wool coated stainless steel outer shield ● Element type: K |
